Dik Geurts

Odin Front – Base

• Brand – Dik Geurts
• Series – Odin
• Category – Wood stoves
• EcoDesign Ready
• Energy efficiency class – A
• Model – Freestanding
• Fire view – Front
• Shape – Round
• Fuel – Wood
• Combustion system – Combustion air from living area
• Glass window – Standard glass
• Door type – Hinged door
• Control Manual control
• Colours – Dark anthracite
• Material – Steel
• Interior – Vermiculite dark anthracite
• Output net min. (kW) – 4,0
• Output net max. (kW) – 8,0
• Nominal heat output – 6.7
• Max. log length (cm) – 33
• Efficiency (%) – 75,2
• CO emission (%-13% O2) – 0,05
• Particulate Matter (mg/Nm3-13% O2) – 31
• OGC/CxHy (mg/Nm3-13% O2) – 67
• NOx emission (mg/Nm3-13% O2) – 140
• Built-in depth (mm) – 380
• Fire view width (mm) – 424
• Fire view height (mm) – 424
• Weight (kg) – 100
• Flue – Top
• Flue Ø (mm) – 150
• External air connection – Base
• Approvals – EN13229, Flamme Verte, BlmSchV, EcoDesign

Odin Front – Fixed

• Brand – Dik Geurts
• Series – Odin
• Category – Wood stoves
• EcoDesign Ready
• Energy efficiency class – A
• Model – Suspended
• Fire view – Front
• Shape – Round
• Fuel – Wood
• Combustion system – Combustion air from living area
• Glass window – Standard glass
• Door type – Hinged door
• Control Manual control
• Colours – Dark anthracite
• Material – Steel
• Interior – Vermiculite dark anthracite
• Output net min. (kW) – 4,0
• Output net max. (kW) – 8,0
• Nominal heat output – 6.7
• Max. log length (cm) – 33
• Efficiency (%) – 75,2
• CO emission (%-13% O2) – 0.05
• Particulate Matter (mg/Nm3-13% O2) – 31
• OGC/CxHy (mg/Nm3-13% O2) – 67
• NOx emission (mg/Nm3-13% O2) – 140
• Built-in depth (mm) – 380
• Fire view width (mm) – 424
• Fire view height (mm) – 424
• Weight (kg) – 100
• Flue – Top
• Flue Ø (mm) – 150
• External air connection – Base
• Approvals – EN13229, Flamme Verte, BlmSchV, EcoDesign

Odin Front – Plateau

• Brand – Dik Geurts
• Series – Odin
• Category – Wood stoves
• EcoDesign Ready
• Energy efficiency class – A
• Model – Freestanding
• Fire view – Front
• Shape – Round
• Fuel – Wood
• Combustion system – Combustion air from living area
• Glass window – Standard glass
• Door type – Hinged door
• Control Manual control
• Colours – Dark anthracite
• Material – Steel
• Interior – Vermiculite dark anthracite
• Output net min. (kW) – 4,0
• Output net max. (kW) – 8,0
• Nominal heat output – 6.7
• Max. log length (cm) – 33
• Efficiency (%) – 75.2
• CO emission (%-13% O2) – 0.05
• Particulate Matter (mg/Nm3-13% O2) – 31
• OGC/CxHy (mg/Nm3-13% O2) – 67
• NOx emission (mg/Nm3-13% O2) – 140
• Built-in depth (mm) – 380
• Fire view width (mm) – 424
• Fire view height (mm) – 424
• Weight (kg) – 100
• Flue – Top
• Flue Ø (mm) – 150
• External air connection – Base
• Approvals – EN13229, Flamme Verte, BlmSchV, EcoDesign

Odin Front – Wall

• Brand – Dik Geurts
• Series – Odin
• Category – Wood stoves
• EcoDesign Ready
• Energy efficiency class – A
• Model – Suspended
• Fire view – Front
• Shape – Round
• Fuel – Wood
• Combustion system – Combustion air from living area
• Glass window – Standard glass
• Door type – Hinged door
• Control Manual control
• Colours – Dark anthracite
• Material – Steel
• Interior – Vermiculite dark anthracite
• Output net min. (kW) – 4,0
• Output net max. (kW) – 8,0
• Nominal heat output – 6.7
• Max. log length (cm) – 33
• Efficiency (%) – 75,2
• CO emission (%-13% O2) – 0.05
• Particulate Matter (mg/Nm3-13% O2) – 31
• OGC/CxHy (mg/Nm3-13% O2) – 67
• NOx emission (mg/Nm3-13% O2) – 140
• Built-in depth (mm) – 380
• Fire view width (mm) – 424
• Fire view height (mm) – 424
• Weight (kg) – 100
• Flue – Top
• Flue Ø (mm) – 150
• External air connection – Base
• Approvals – EN13229, Flamme Verte, BlmSchV, EcoDesign

Dik Geurts – Instyle Corner Slim 660/495

This two-sided Instyle Corner Slim 660/495 fire is unique in the market due to its panoramic fire view. The glass is placed in the corner against each other. The continuous glass window, without a metal corner post between the two glass panes, provides a full view of the fire. Only available at Dik Geurts.

Dik Geurts – Instyle Triple 660 Low

The Instyle Triple 660 Low is a 3-sided panoramic wood stove that can be build into a pre-fabricated chimneybreast or a room dividing feature wall. At only 495 mm high, it is a flexible and versatile woodburning fire. As well as the all-round vision of its flame picture, the side panels are made of infra-red heat reflective glass.

Dik Geurts – Prostyle Tunnel

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle Tunnel is a see-through wood stove that can be build into a pre-fabricated chimneybreast or room dividing wall. With hinged doors on either side, it is both stunning and practical. It has a heat output range from 9 – 12 kW and an efficiency rating of 83%.

Dik Geurts – Instyle 550

The Instyle 550 is designed for insertion into a Class 1 UK brick chimney. It can be combined with a classic fire surround and hearth to create a traditional fireplace. It has a heat output range from 3 – 7 kW, an efficiency rating of 87% and it has DEFRA approval for use in UK urban smokeless zones.

Dik Geurts – Instyle Corner 660 High

The Instyle Corner 660 High is a 2-sided corner wood stove that can be build into a pre-fabricated chimneybreast or used as a part of a room dividing wall. It has a heat output range from 7 – 11 kW and an impressive energy efficiency rating of 83%.

Dik Geurts – Instyle 1000

The Instyle 1000, 1 metre wide wood stove can be inserted into a standard UK brick chimney. It can also be build into a pre-fabricated chimneybreast to create a spectacular letterbox-style wood fire. It has a heat output range from 9 – 13 kW and an impressive energy efficiency rating of 78%.

Dik Geurts – Instyle Corner 660 Low

The Instyle Corner 660 Low is a 2-sided corner wood stove that can be build into a pre-fabricated chimneybreast or used as a part of a room dividing wall. At only 345 mm high, it is a flexible and versatile woodburning fire. It has a heat output range from 6 – 9 kW and an impressive energy efficiency rating of 83%.

Dik Geurts – Instyle 650

The Instyle 650 can be installed into a chimney or false chimneybreast. This stylish insert wood fire is available with a selection of frames to enhance its visual appeal, including: Classic Line, Modern Line, Panoramic or Slim line. It has a heat output range from 5 – 9 kW and an impressive energy efficiency rating of 81%.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Instyle 700

The Instyle 700  can be installed into a chimney or false chimneybreast. This stylish insert wood fire is available with a selection of frames to enhance its visual appeal, including: Classic Line, Modern Line, Panoramic or Slim line. It has a heat output range from 8 – 12 kW and an energy efficiency rating of 82%.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Instyle 600

The Instyle 600 is suitable for insertion into a standard UK brick chimney. It can stand alone or be combined with a classic fire surround. This stylish insert wood fire is available with a selection of frames to enhance its visual appeal, including: Classic Line, Modern Line or Slim line versions. Energy efficiency is 80%.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Instyle Tunnel

The Instyle Tunnel is a see-through wood stove that can be build into a pre-fabricated chimneybreast or used as a part of a room dividing wall. With hinged doors on either side, it is both visually impressive and practical. It has a heat output range from 9 – 12 kW and an impressive energy efficiency rating of 83%.

Dik Geurts – Instyle 500

The Instyle 500 can be installed into a standard UK brick chimney. It can be used as a hole in the wall wood fire insert or combined with a classic fire surround and hearth. This stylish insert wood fire is available with a selection of frames, including: Classic Line, Modern Line or Slim line.

Dik Geurts – Instyle 800

The Instyle 800, with a width of 80 cms, can be installed into a standard UK brick chimney or pre-fabricated chimney as a widescreen wood burning fire. It has a heat output range from 8 – 12 kW and an impressive energy efficiency rating of 77%.

Dik Geurts – Prostyle 650

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 650 is designed for a standard chimney. It can be used as a simple wood fire insert. It can also be combined with a standard or panoramic frame or even with a classic fire surround and hearth to create a more traditional log fireplace.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Prostyle 700

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 700 can be installed into a standard chimney. It can be a simple hole in the wall wood fire insert. It can also be combined with a standard or panoramic frame or even with a classic fire surround and hearth to create a traditional log fireplace.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Prostyle 1000

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 1000, at 1 metre wide, can be combined with a standard or panoramic frame or even with a classic fire surround and hearth to create a traditional fireplace. It has a heat output range from 9 – 13 kW and an impressive efficiency rating of 77%.

Dik Geurts – Prostyle 800

Dik Geurts – Instyle 700V Next

The Instyle 700V Next, at 70 cms wide, can be build into a standard chimney or combined with a classic fire surround and hearth. A special feature of this insert wood stove is the optional fan-assisted ventilation, which electrically enhances the heating power of the fire. Furthermore, it has DEFRA approval for use in UK smokeless zones.

Dik Geurts – Prostyle 550

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 550 is the ideal size for a brick chimney. It can be used as a hole in the wall wood fire. It can also be combined with a standard or panoramic frame or even with a classic fire surround and hearth to create a traditional fireplace.

Dik Geurts – Prostyle 600

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 600 is suitable for a standard UK brick chimney. It can be a simple hole in the wall wood fire insert. It can also be combined with a standard or panoramic frame or even with a classic fire surround and hearth to create a more traditional fireplace.

The ‘Build-in frame’ is available as a 3mm frame as well as an 8mm frame.

Dik Geurts – Instyle 600V Next

The Instyle 600V Next , at 60 cms wide can be build into a standard UK brick chimney. It can be used as a hole in the wall wood fire insert or combined with a classic fire surround and hearth to create a more traditional log fireplace.

Dik Geurts – Instyle 800V Next

The Instyle 800V Next, with a width of 80 cms, can be installed into a standard UK brick chimney. It can also be build into a pre-fabricated chimney as a widescreen hole-in-the-wall wood burning fire. A special feature of the Instyle 800V Next insert wood stove is the optional fan-assisted ventilation, which electrically enhances the heating power of the fire.

Dik Geurts – Prostyle 500

Prostyle fires have screen-printed glass that conceals the metal frames. The Prostyle 500 is the ideal size for insertion into a standard UK brick chimney, with optional fire surround and hearth. It can also be combined with a selection of elegant frames, including: Classic Line, Modern Line, Panoramic or Slim line versions.

Dik Geurts – Instyle Corner Slim 660/570

A full view of the fire from your living room. With the extension of Instyle Corner Slim into a higher version, Dik Geurts offers a solution for all existing situations. Enjoy the full flames through the unique free fire view and glass on glass in the corner. Because the side window is fitted with infrared glass, there is optimal combustion and excellent efficiency.
